| 类型 | 配置 |
| CPU | Dual AMD EPYC™ 7002/7003* series Processors Socket SP3 Up to 280W TDP |
| Cores | Up to 64 Cores |
| Chipset | System on Chip |
| Memory Capacity | 16 DIMM sockets Supports up to 2TB Registered ECC DDR4 2666MHz SDRAM Supports up to 4TB Registered ECC DDR4 3200MHz SDRAM 8-channel memory bus |
| Memory Type | DDR4 2666 MHz Registered ECC, 288-pin gold-plated DIMMs DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB |
| Memory Voltage | 1.2V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| SATA | SATA3 (6 Gbps) |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC |
Network Controllers | Intel® i350 1G Base-T Ethernet Controller 1 Realtek RTL8211E PHY (dedicated IPMI) |
| VGA | ASPEED AST2500 BMC |
| SATA | 10 SATA3 (6 Gbps) ports |
| PLX Switch | 2 PLX88096 PCIe 4.0 Chip |
| LAN | 2 RJ45 1GBase-T ports 1 RJ45 Dedicated IPMI LAN port |
| USB | 2 USB 3.0 ports (rear) 4 USB 2.0 ports (2 rear + 2 via header) |
| VGA | 1 VGA port |
| Others | COM port (rear) 2 SATA DOM power connectors 1 TPM 2.0 header |
| PCI-Express | 3 PCI-E 3.0 x8 10 PCI-E 4.0 x16 |
| M.2 | Interface: 1 SATA/PCI-E 3.0 x2(Platform with EPYC 7002 processor only supports PCI-E type M.2 module) Form factor: 2280, 22110 Key: M-key |
| BIOS Type | AMI 128Mb SPI Flash EEPROM |
| BIOS Features | Plug and Play (PnP) DMI 2.3 PCI 2.2 ACPI 5.1 USB Keyboard Support SMBIOS 3.1.1 |
